Karpenter: The Intelligent Autoscaler for EKS

Discover Karpenter, the modern autoscaler designed for EKS — faster, more flexible, and more cost-efficient than the traditional Cluster Autoscaler.

I. What is Karpenter?

Karpenter is an open-source autoscaler for Kubernetes, created by AWS.
Its purpose is to automatically adjust the EC2 node capacity of an EKS cluster based on real workload demand.

In short:

• When your cluster is short on resources, Karpenter adds new nodes.
• When nodes become unnecessary, it removes them.

But more importantly:

It does this faster, more intelligently, and more efficiently than Kubernetes’ traditional autoscaler (Cluster Autoscaler).

In this article, we explore:

• why Karpenter exists
• what it does better than Cluster Autoscaler
• how it works
• the pitfalls to avoid in production
• and why it has become a must-have component for EKS

II. Why does Karpenter exist?

The native Kubernetes Cluster Autoscaler (CA):

• can only manage Auto Scaling Groups (ASG)
• launches instances from a fixed, predefined list
• often takes several minutes to react
• does not evaluate all EC2 instance options
• performs poorly with Spot capacity

Karpenter fixes all of these issues.

III. What Karpenter does better

1. It dynamically chooses the best instance type

No need to manually list dozens of instance types inside an ASG.

Karpenter can decide automatically:

• t3 or c6i?
• a large instance or multiple small ones?
• Spot or On-Demand?
• which AZ still has available capacity?

It selects the instance at the moment of need, based on:

• Spot availability
• price
• CPU/RAM/GPU requests from pods
• constraints (architecture, disk size, labels, taints…)

2. It launches nodes in 10 to 30 seconds

Much faster than:

• Cluster Autoscaler (acts through ASGs)
• the ASG engine itself (which has its own delays)

Karpenter creates nodes directly via the EC2 API — extremely fast.

3. It automatically handles unused nodes

If a node becomes empty (no useful pods), Karpenter:

• cordons it
• drains it
• then terminates it

Result: lower costs and a cleaner cluster

4. It handles Spot interruptions gracefully

When AWS announces a Spot interruption:

• Karpenter receives the signal
• evicts pods and reschedules them
• spins up a replacement node immediately

Very helpful during difficult periods… like December (see the article on Spot availability in December).

IV. How does it work?

Karpenter relies on a Custom Resource:

Provisioner

This object defines:

• allowed instance types
• usable availability zones
• maximum resource quotas
• Spot / On-Demand preferences
• minimum / maximum node sizes

Then Karpenter watches Pending pods and creates the perfect node to host them.

V. Minimal Provisioner Example

apiVersion: karpenter.sh/v1alpha5
kind: Provisioner
metadata:
  name: default
spec:
  requirements:
    - key: karpenter.sh/capacity-type
      operator: In
      values: ["spot", "on-demand"]
  limits:
    resources:
      cpu: 500
  provider:
    subnetSelector:
      kubernetes.io/cluster/my-cluster: owned
    securityGroupSelector:
      kubernetes.io/cluster/my-cluster: owned

Karpenter vs Cluster Autoscaler

VI. Common issues with Karpenter

1. Over-provisioning risks (scaling too aggressively)

Karpenter is much faster than Cluster Autoscaler — sometimes too fast.

Symptoms:

• more nodes created than necessary
• nodes becoming unused shortly after creation
• AWS costs temporarily spiking
• nodes removed later — but still billed

Cause:
Karpenter reacts instantly to pods in Pending, even when those pods should not actually be scheduled.

How to avoid:

• enable consolidation
• configure maxPods and realistic CPU/RAM requests
• set strict limits in the Provisioner

limits:
resources:
cpu: 200

2. Deprovisioning that is “too” effective

Karpenter removes nodes that appear unused.

Possible issues:

• some DaemonSets or system pods make a node appear “empty” but not removable
• temporary workloads cause oscillations
• scale-in may be too aggressive, causing immediate recreation → ping-pong effect

Solutions:

• increase ttlSecondsAfterEmpty
• use taints to protect certain nodes
• enable progressive consolidation

3. Required integration with VPC, IAM, and AWS tags

Karpenter cannot operate without:

• a proper IAM Role
• correctly tagged Subnets
• tagged Security Groups
• advanced EC2 permissions

Mandatory tags:

kubernetes.io/cluster/<cluster-name>: owned
karpenter.sh/discovery: <cluster-name>

Without these tags, no node can be created.

4. Unexpected behavior with heavy DaemonSets

Examples:

• Prometheus Node Exporter
• Falco
• Cilium
• Heavy logging agents (Datadog, New Relic…)
• CSI EBS/EFS (depending on the version)

Why?

Karpenter chooses node sizes based on actual pod resource consumption.

If DaemonSets consume too much:

• small nodes → crashloops
• large nodes → unnecessary cost

Solutions:

• define realistic resources.requests
• exclude some DaemonSets using taints
• use dedicated Provisioners (e.g., system-nodes)

5. Spot + Karpenter = excellent… but sensitive to shortages

During high-demand periods (e.g., December), Karpenter may:

• test multiple instance families
• reschedule repeatedly
• try different AZs
• loop until it finds capacity

This may cause:

• instability
• Spot node flapping
• increased latency

Key advice: Never rely on 100% Spot. Always maintain an On-Demand baseline, e.g.:

on-demand: 20–40%

6. It can break an existing ASG strategy

Many infrastructures use:

• an On-Demand ASG + a Spot ASG
• autoscaling policies
• lifecycle hooks
• warm pools

Karpenter ignores ASGs entirely.
It creates instances directly through the EC2 API.

If your architecture relies on:

• EC2-based scaling
• lifecycle hooks
• warm pools

You will lose these mechanisms when migrating to Karpenter.

7. Unexpected costs due to oversized instances

Karpenter optimizes for:

• pod scheduling
• availability
• speed

…but not necessarily for the lowest cost.

Classic example:

“I requested 2 CPU and 4 GB…
Why did Karpenter launch an m6i.2xlarge?”

Possible reasons:

• small Spot sizes unavailable
• larger instance temporarily cheaper
• DaemonSets forcing a minimum size

Solution:
restrict instance families/types in your requirements.

8. Dangerously permissive Provisioners

Example:

requirements:
  - key: karpenter.sh/capacity-type
    operator: In
    values: ["spot"]

If Spot capacity disappears:

• no nodes can be created
• cluster down

Always:

• include On-Demand
• limit instance families
• set fallback AZs

9. More frequent pod interruptions

Example:

• Karpenter consolidates
• removes an “empty” node
• a DaemonSet schedules right after
• the node was actually needed

Result:

• unnecessary pod rescheduling → micro-interruptions
• temporary instability → degraded performance

Solution: increase TTLs or disable consolidation at certain hours.

The 9 Karpenter Pitfalls to Watch

Conclusion

Karpenter is an outstanding tool, especially for:

• optimizing costs
• accelerating scaling
• using Spot instances effectively
• simplifying node lifecycle management

But because it is extremely powerful,
it must be configured carefully.

Well-managed, it is one of the best tools available for EKS today.
